One.SCADA^™

The Ignition platform is the foundation of every Ignition system. It includes powerful features and core drivers to connect all your industrial data and devices in a central hub. It is also the basis for additional modules.

Unlimited Tags

Use as many tags as you need for devices, databases, and anything else.

The visualization module for cutting-edge modern industrial applications. Quickly build full-featured industrial applications for monitoring and control, using the latest mobile-responsive, pure-web technology. Perspective applications are build-once, run-anywhere-compatible with three distinct deployment technologies that give you a wide range of options. Deploy directly to web-browsers for a modern, pure-web experience. Leverage the native mobile applications to gain access to hardware features such as the device’s accelerometer, Bluetooth connectivity, geolocation, barcode scanning, and more. Finally, leverage Perspective Workstation to add full kiosk mode and multi-monitor support, perfect for control rooms, touch panels, and HMIs. Perspective gives you total freedom to visualize and control your process however you want, on whatever device you want.

The visualization module for plant-floor and desktop screens. Display charts, graphs, trends, HMI screens, embed web browser components, and more, anywhere on the network.

Easily create dynamic, database driven PDF reports with pixel perfect layouts.

Easily bridge the gap between OPC data and SQL databases with the industry\\\'s most flexible and powerful transaction manager. Easily log data, call stored procedures, and synchronize data bi-directionally.

Utilize built-in data historians, easy connectivity to external SQL databases, open technology, and a library of tools to build a historian solution for nearly any application.

Historian Core Module

Leverage the powerful, built-in Core Historian, the Internal Historian (Legacy), and a library of historian tools for your solutions.

SQL Historian Module

Combine Ignition with external SQL databases to create a high-performance historian.

Streamline the creation, organization, and visualization of robust logic systems.

Create a communication pipeline between various sources (such as tag changes or Kafka topics) and handlers (like scripts or database tables). Effortlessly connect disparate industrial and enterprise subsystems for data sharing, filtering, and transformation, all natively within Ignition.

This module allows users to directly program against the web server inside the Ignition Gateway. Great for providing REST endpoints using Python. Also provides a simple way to serve out files as static web resources when needed.

Configure the logic for how, why and when alarm notifications are delivered, manage alarm notification for groups of users, and send notifications via email.

Voice Notification Module

Notify users of alarms via a phone call. Alarm details are annunciated using text-to-speech, and users can acknowledge via touch-tone. Requires a VoIP system such as Skype or any SIP-compatible VoIP gateway. One voice included, additional voices required for multiple languages; $235/ea. Requires the Alarm Notification Module and a SIP-compatible VoIP service. An IP telephony gateway can be used to bridge to a standard phone line (not included).

SMS Notification Module

Notify users of alarms via text message. Reply via text to acknowledge alarms. This module requires the Alarm Notification Module and an AirLink RV50/RV50X, RV55/RV55X, Raven XE, LS300, or LX40 with a data and SMS cellular plan (not included).

Twilio Notification Module

Adds integration with Twilio for both SMS and voice notifications, along with WhatsApp SMS notifications.

Multiply the power of your Ignition Gateways by combining them into an enterprise network. Streamline the administration, monitoring, deployment, and commissioning process into one central location (the Controller). One EAM Module is required for every Ignition Gateway on your network, and can function as either the Controller or Agent.

Connect to classic OPC servers using DCOM. For Windows® only. Use OPC DA (Data Access) for real-time status and control. Includes OPC HDA (Historical Data Access) support to query third-party historian products.

The SECS/GEM Module enables Ignition projects and third-party applications to communicate with semiconductor fab equipment.

Enable connectivity to Kafka to process event stream data from a Kafka source or publish it to a Kafka topic.

Add connectivity to MongoDB for flexible document data models and a NoSQL database. Easily store, index, retrieve, and query data or tags for use in reports.

Connect to Siemens S7-300 and S7-400 PLCs using absolute addressing, or to S7-1200 and S7-1500 PLCs using either absolute or symbolic addressing.

This driver connects to the following Opto22 products: SNAP‑PAC‑R1, SNAP‑PAC‑R2, SNAP‑PAC‑S1, SNAP‑PAC‑S2, SOFTPAC, GRV‑EPIC‑PR1.

Connect to the following device families: Emerson ROC 107, 300 & 800 Series flow computers. EFM driver supports real-time, alarm, historical, and event data. No module prerequisites to connect to real-time data(TLPs) from the Edge or Central Server implementations. If obtaining alarm, configuration, historical, or event data described as Data Records – MQTT components are required within the architecture. MQTT Transmission to publish, MQTT Engine to subscribe and MQTT Recorder to insert into SQL Databases. One connection supports up to 15 Emerson ROC devices. Bulk pricing is available, contact us for pricing or any questions.

Connect to the following ABB Totalflow device families: G2 Late, G3, G4 Early, G4 Late, and G5 series flow computers. EFM supports real-time, alarm, historical, and event data. Requires the OPC UA Server Module, MQTT Transmission Module, MQTT Engine Module, and the Recorder Module for alarm, historical, and event data. One connection supports up to 15 ABB Totalflow devices. Bulk pricing is available.

Bidirectionally communicate with edge-of-the-network devices securely via an MQTT Server. Create one pipeline for all your IIoT data that increases throughput and efficiencies of data acquisition throughout the enterprise.

Adds an MQTT server to the Ignition platform that enables MQTT clients to securely connect, publish, and subscribe to data. Enable MQTT clients for operational and business applications to connect to IIoT data throughout the enterprise. With a limit of 50 simultaneously connected clients and its ability to run as a module on Ignition, The MQTT Distributor Module is ideal for smaller solutions.

Enable Ignition to quickly and easily create connections to MQTT servers and start publishing TAG data via MQTT.

The AWS Injector module enables end users of Ignition to select tag data from the Ignition platform to be sent into the Amazon Web Services (AWS) cloud infrastructure for analytics. With a simple configuration, tag data will flow into the AWS Kinesis Streams or DynamoDB using an easy to read JSON representation to take full advantage of AWS and all the benefits it offers.

The Azure Injector module enables end users of Ignition to select tag data from the Ignition platform to be sent into the Microsoft Azure cloud infrastructure through the Azure IoT Hub. With a simple configuration, tag data will flow into the Azure IoT Hub using an easy to read JSON representation enabling the access of Big Data & Analytics of operational data.

The Google Cloud Platform Injector Module enables end users of Ignition to select tag data from the Ignition platform to be sent into the Google Cloud Platform infrastructure for analytics. With a simple configuration, tag data will flow into the Google Cloud Platform, giving users easy access to all tools and big data analysis the platform has to offer.

The MQTT Recorder Module receives record objects from the MQTT Engine Module that have arrived via MQTT/Sparkplug. Utilizing a database that is configured within Ignition, the MQTT Recorder Module automatically generates database tables and populates the rows within the tables with records as they are received. Records represent a collection of tags, fields, and key-value pairs. They are especially useful for receiving records from a flow computer of its events, alarms, and historical data.

Ignition Edge IIoT turns a field device into an MQTT-enabled edge gateway and an EAM agent gateway. It also enables scripting and remote data synchronization at the edge.

Cross-Platform

Works seamlessly with most computing platforms and can run on virtually any edge device.

Unlimited Tags & Devices

Includes unlimited tags and device connections for included drivers, and acts as an OPC UA server so it can connect with most PLCs.

Transmit & Synchronize Data from the Edge

Uses Edge to transmit data to any MQTT broker using the Sparkplug specification and acts as a limited remote server that synchronizes data from the edge to a central Ignition server.

Remote EAM Agent Gateway

Acts as a remote EAM Agent Gateway, working with a central Ignition server that has the Enterprise Administration Module (EAM).

Run Scripts at the Edge

Able to run scripts and create REST APIs for interfacing with third-party applications from the edge.

Add local visualization and control with powerful HMI software for field devices that can publish data and synchronize with a central Ignition system. Edge Panel includes all the features of Edge IIoT plus local visualization capabilities for your HMIs with Perspective (2 sessions) or Vision (1 local client, 1 remote client).

Cross-Platform

Works seamlessly with most computing platforms and can run on virtually any edge device.

Unlimited Tags & Devices

Includes unlimited tags and device connections for included drivers, and acts as an OPC UA server so it can connect with most PLCs.

Transmit & Synchronize Data from the Edge

Uses Edge to transmit data to any MQTT broker using the Sparkplug specification and acts as a limited remote server that synchronizes data from the edge to a central Ignition server.

Remote EAM Agent Gateway

Acts as a remote EAM Agent Gateway, working with a central Ignition server that has the Enterprise Administration Module (EAM).

Run Scripts at the Edge

Able to run scripts and create REST APIs for interfacing with third-party applications from the edge.
